• Max. cutting capacity 45° mitre/ 45° bevel: 241 x 57 mm.
• Max. cutting capacity 45° mitre/ 90° bevel: 241 x 102 mm.
• Max. cutting capacity 90° mitre/ 45° bevel: 342 x 57 mm.
• Max. cutting capacity 90° mitre/ 90° bevel: 342 x 102 mm.
• 1800 Watt direct drive motor ensures a quick, clean cut even in hardwood materials.
• Dual integral jobsite lights illuminate the cut line.
• Integral dust channel captures 75% of all dust by capturing dust near the cut on both sides of the blade and directing it to the back of the saw.
• Unique inline motor design - for excellent visibility from both sides to the work piece and better balanced transport.
• Mitre capacity 55° to the left and 60° to the right – for maximum versatility. Mitre detents L & R at: 0°, 15°, 22.5°, 31.6°, 45°, 60°.
• Dual-bevel design – to incline the saw head left and right 0° – 48° with bevel detents L & R at: 0°, 22.5°, 33,85°, 45°, 48°.
• Fast and accurate bevel adjustment.
• Supplied with Work piece clamp, saw blade (60 teeth), vacuum adaptor ø35 / 58 mm, wrench and 3 m cable.
Symbol | MS304DB |
Moc [W] | 1800 |
Zasilanie | network |
Średnica tarczy | 305.00 |
Obroty [obr/min] | 3900 |
