M18 FPD2
• Voltage: 18 V
• Max. drilling masonry/steel/wood: 16/16/89 mm
• Max. percussion rate: 0 - 32000 bpm
• Max. torque: 135 Nm
• No load speed gear 1/2: 0-550/0-2000 rpm
• Battery type: Li-ion
• Chuck capacity: 13 mm
• Weight with battery pack: 2.2 kg
• Higher power efficiency under load - outstanding torque of 135 Nm.
• Extremely compact design of 175 mm length for access into tight spaces.
• Advanced heavy duty chuck providing increased bit grip.
• Brushless POWERSTATE™ motor for heavy application under load.
• 13 mm metal chuck for quick bit changes and bit retention.
• REDLITHIUM™ battery pack provides superior pack construction, electronics and fade-free performance to deliver more run time and more work over pack life.
• Individual battery cell monitoring optimises tool run time and ensures long term pack durability.
• Battery fuel gauge displays remaining charge.
• 40 percent brighter LED workspace illumination - vs previous model.
• All metal reversible belt clip to hang your tool quickly and easily.
• Flexible battery system: works with all MILWAUKEE® M18™ batteries.
M18 FID2
• Voltage: 18 V
• Impact rate: 1200/3400/4300/0-4300 ipm
• No load speed: 1900/2800/3600/0-3600 rpm
• Max. torque: 119/176/226/0-226 Nm
• Max. fastening torque: 226 Nm
• Max. bolt diameter: M16
• Battery type: Li-ion
• Weight with battery pack: 1.7 kg
• Sound pressure level: 96.75 dB(A)
• Sound power level measured: 107.75 dB(A)
• Higher power efficiency under load - outstanding torque of 226 Nm.
• Faster driving speed vs. previous model - up to 3600 rpm and 4300 ipm.
• Extremely compact design - total length of just 117 mm for access into tight spaces.
• DRIVE CONTROL allows the user to shift into four different speed and torque settings to maximise application versatility.
• Mode 1 for precision work.
• Mode 2 helps prevent damage to fasteners and material.
• Mode 3 delivers maximum performance for the toughest applications.
• Mode 4 is the optimum between precision work and maximum performance and automatically adjusts speed, impacts and torque.
• Brushless POWERSTATE™ motor for heavy application under load.
• REDLINK PLUS™ intelligence system delivers an advanced digital overload protection for tool and battery and uniquely enhances the tool performance under load.
• REDLITHIUM™-ION battery pack provides superior pack construction, electronics and fade-free performance to deliver more run time and more work over pack life.
• 1/4" Hex chuck for quick and easy bit change.
• Flexible battery system: works with all MILWAUKEE® M18™ batteries.
• Standard equipment: belt clip and bit holder.
M18 FHX
• Voltage: 18 V
• Blow energy: 2.5 J
• Max. percussion rate: 0-4800 bpm
• No load speed: 0-1330 rpm
• Max. drilling wood/steel/concrete: 28/13/26 mm
• Vibration drilling: 12.9 m/s²
• Vibration chiseling: 14.2 m/s²
• Tool reception: SDS-Plus + Reduced shank 13 mm
• Battery type: Li-ion
• Weight with battery pack (M18 HB5.5): 4.5 kg
• The fastest drilling rotary hammer in its class leading to increased productivity.
• Powerful hammer mechanism delivers 2.5 J of impact energy at low 12.9 m/s² vibrations.
• Drills up to 125 Ø10 x 50 mm holes on a M18™ HIGH OUTPUT™ 5.5 Ah battery charge.
• AUTOSTOP™ shuts down the tool to protect the user of sharp movement in bind up situations.
• FIXTEC™ system for keyless chuck changing between SDS-Plus and 13 mm metal chuck.
• All metal gear case - optimum seating of the gears for enhanced tool life.
• 4-mode operation: rotary hammer, hammer only, rotation only and selectable work position of the chisel (variolock) for maximum versatility.
• Compatible with M18 FCDDEXL or M18 FDDEXL dust extractors.
• The DNA of our FUEL™ platform redefines the balance of cordless technologies. MILWAUKEE®'s POWERSTATE™ brushless motor,
REDLITHIUM™ battery pack and REDLINK PLUS™ electronic intelligence delivering outstanding power, run time and durability.
M18 ONEFSAG125XB
• Voltage: 18 V
• Disk diameter: 125 mm
• No load speed: 8500 rpm
• Max. cutting depth: 33 mm
• Switch type: slide lock-on switch
• Brake: yes
• FIXTEC™: yes
• Anti-kickback protection: yes
• Line lock out function: yes
• Battery type: Li-ion
• Weight with battery pack (M18 B5): 2.7 kg
• Delivering corded performance similar to a 1200 W grinder.
• ONE-KEY™ tool tracking & security offers a free of charge cloud-based tracking network and inventory management platform for your tools.
ONE-KEY™ also features a remote locking functionality.
• RAPIDSTOP™ for fastest disc brake in less than 2 seconds and best user protection.
• Reduced gearhead size and lower angle of battery slot - for better balance & ergonomics compared to previous model.
• Anti-vibration side handle for lower vibration.
• Integrated FIXTEC™ system for tool-free wheel change.
• Slim handle design.
• Removable dust screen to prevent debris entrance, prolonging motor life.
• 125 mm keyless guard for great cutting capacity and fast guard adjustment without using a key.
• Line-lock-out function to prevent automatic start up.
• The DNA of our FUEL™ platform redefines the balance of cordless technologies. MILWAUKEE®'s POWERSTATE™ brushless motor,
REDLITHIUM™ battery pack and REDLINK PLUS™ electronic intelligence delivering outstanding power, run time and durability.
• Flexible battery system: works with all MILWAUKEE® M18™ batteries.
• Supplied in case (PACKOUT) with 3 batteries and charger.
